Standardized Multi-Device Power Supply Systems
29 January 2025 - REGATRON introduced the G5 power supply family. The basic idea is to integrate from a single up to 6 units G5/54 kW devices into a common cabinet to cover the power range from 54 kW up to 324 kW and system voltages up to 3000 VDC. The standardized design has the advantage that the entire wiring on the mains side, including the main switch, is fully integrated and a sophisticated conductor design on the DC side allows the type of circuit (parallel, series or matrix) to be changed at any time to adapt the DC voltage or current range. A whole selection of useful options completes the new products.
The versatile REGATRON G5 power supply units are often used in various wiring combinations to meet the customers desired system voltage, power or current requirements. It was therefore reasonable to develop a series of standardized device combinations in addition to the individual devices.
At a Glance
- 54 kW to 162 kW units with castors, 216 kW to 324 kW on a base frame for forklifter
- Voltage ratings from 500 to 3000 VDC
- Current ratings from 108 to 1944 ADC
- Emergency stop button for safety category 3, level PL (e) according to EN ISO 13849
