Latest Test and Measurement NewsPXI Multifunction Instrument combining Measurement and Control Functions
Battery Pack Integrated Testbed for Electric Vehicles
Multi-Channel AWG and Digitizer in one Box
First 10 GHz Oscilloscope with 4, 6 or 8 Channels
Background: Leveraging the true Value of your Test AssetsWe live in an era where technology companies can be vast, sprawling operations with numerous different sites. This means that it is increasingly difficult to keep complete visibility of the test equipment held in stock. Often an item that could be of particular use to an engineer within an organisation might be located in a corner of some dusty storeroom, effectively forgotten about. As all technology-related sectors look to slowly drag themselves out of the acute global slump that COVID-19 has caused, there is a real need to make testing workflows more efficient and to maximise utilisation of the assets involved. Signal and Spectrum Analyzer with 8.3 GHz internal Analysis Bandwidth
First 200Gb PAM4 Ethernet Protocol Analyzer
More Articles ...
Related Articles: |
Upcoming EventsTag CloudOscilloscope
JTAG
Boundary Scan
Goepel
PXI
Rohde & Schwarz
Tektronix
Keysight
AOI
Anritsu
National Instruments
Inspection
Teledyne LeCroy
Aeroflex
LTE
Yokogawa
AXI
Spectrum Analyzer
Keithley
In-Circuit-Test
Signal Analyzer
Automotive
EMC-Test
Signal Generator
Advantest
Multitest
B&K Precision
Corelis
Power Supply
SPI
Flying Prober
Teseq
Cognex
Switching
Teradyne
Viscom
Pickering
Fluke
GAO Tek
PCIe
RSS Feed
Subscribe to RSS Feed
Social Media
|
||
|
© All about Test 2018 |
||||
How to resolve AdBlock issue?
22 September 2020 - Marvin Test Solutions launched the new GX3722 Series Multifunction Analog and Digital I/O Instrument. The GX3722 delivers exceptional flexibility and utility, with a unique mix of measurement and control functionality, in a single high-performance 3U PXI hybrid slot compatible instrument. Analog measurement capabilities include four time-interval channels, each rated at 10 MHz, with channels supporting both 50 Ohm and 75 Ohm input impedance. Two digitizer channels, each with a maximum sampling rate of 10 MS/s, include programmable input impedance and sampling rates with a 24 Vpp input range.
21 September 2020 - The battery pack is the most important component of EVs and its verification takes automotive OEMs much effort. However, the battery pack keeps causing the most potential problems. Most test systems for battery packs, so far, mainly perform a charge/discharge life test. Some advanced ones are equipped with BMS communication to simulate the battery pack's response under different conditions. Still, this is far off from the actual operation of the battery pack in real vehicles.
18 September 2020 - The hybridNETBOX of Spectrum Instrumentation is an exciting new instrumentation platform for applications that require simultaneous signal generation and acquisition. Six models are available offering the choice of two, four or eight pairs of matched AWG and digitizer channels, with output- and sampling-rates of 40, 80 and 125 Megasamples per second.
17 September 2020 - Tektronix announced the availability of the new 6 Series B Mixed Signal Oscilloscope (MSO) which extends the performance threshold of the Tektronix Mainstream Oscilloscopes Portfolio to 10 GHz and 50 GS/sec. Developed to meet the demand for high-speed data movement and processing in embedded designs, the enhanced 6 Series B MSO offers leading signal fidelity with 12-bit ADCs and extremely low noise, 10 GHz bandwidth and up to 8 FlexChannel inputs, enabling users to confidently analyze and debug today's embedded systems while enjoying exceptional ease of use.
15 September 2020 — Rohde & Schwarz launched the new R&S FSW-B8001 option. It extends the internal analysis bandwidth of the R&S FSW high-end signal and spectrum analyzer to 8.3 GHz. Covering an input frequency range of up to 90 GHz, the instrument provides an unmatched dynamic range and sensitivity, precision and EVM performance. Equipped with the extended analysis bandwidth option and dedicated measurement applications, the signal and spectrum analyzer meets current and future test and measurement requirements for ultra wideband signal analysis across different industries.
14 September 2020 – Teledyne LeCroy announced the support for complete analysis of IEEE 802.3cd based 200GbE Pulse Amplitude Modulation (PAM4) ethernet links in the SierraNet M648 Ethernet and Fibre Channel Protocol Test System with the latest Net Protocol Suite software version 4.30. SierraNet M648 offers extensive and deep Ethernet protocol analysis, including InFusion traffic impairment tools for both NRZ and PAM4 signaling and is the only dedicated analysis tool in the market to offer complete test and network validation tools covering the full range of ethernet speeds and protocols available.
